General Description
M4TXX-BR12SH General Description
The M4Txx-BR12SH SNAPHAT top is a detachable lithium power source for ST's non-volatile TIMEKEEPER surface mount SOIC (MH) package (28 and 44 pin).
The SNAPHAT top contains both the battery and crystal and is designed to be "snapped on" after the SOIC is surface mounted on the PC board. Thus the two piece solution avoids the battery and crystal from having to be exposed to the high temperatures of the surface mount process.
M4TXX-BR12SH Features
`Provides Battery Backup Power for Non-Volatile
TIMEKEEPERs and Controllers in the SNAPHAT SOIC Package
` Removable Battery Avoids Heat Associated with Surface Mount Process
` Snaps Directly onto Surface-Mounted
SNAPHAT SOIC
` Choice of Battery Capacities
M4T28-BR12SH = 48 mAh
M4T32-BR12SH = 120 mAh
` Keyed Insertion to Insure Proper Assembly
` Removable for Replacement and Proper Disposal
` Available in Tubes or Tape & Reel
` For Use with the 28 and 44 pin SOIC Versions of the TIMEKEEPER Product Families
TIMEKEEPERs and Controllers in the SNAPHAT SOIC Package
` Removable Battery Avoids Heat Associated with Surface Mount Process
` Snaps Directly onto Surface-Mounted
SNAPHAT SOIC
` Choice of Battery Capacities
M4T28-BR12SH = 48 mAh
M4T32-BR12SH = 120 mAh
` Keyed Insertion to Insure Proper Assembly
` Removable for Replacement and Proper Disposal
` Available in Tubes or Tape & Reel
` For Use with the 28 and 44 pin SOIC Versions of the TIMEKEEPER Product Families
