M52693SP

 ·Low power dissipation of supply voltage 5.0V and circuit current 32mA (Typ.)
 ·Built-in 4fsc burst lock clock generator circuit required for digital video signal processing
 ·Small picture chroma level following main picture burst level
 ·Main picture pedestal level matching small picture pedestal level
 ·Built-in reference voltage source for A/D converter

The M52693SP is a semiconductor integrated circuit developed for analog signal processing of a picture-in-picture system, consisting of a sync separator, an ACC, a burst lock clock generator circuit,an analog switch and a clamp circuit, etc. It is also available on digital video signal systems other than the above.
