MFG:MIT Package Cooled:SMD D/C:2003
MFG: MIT
Package Cooled: SMD
D/C: 2003
Description: M52769FP is a semiconductor integrated circuit consisting of VIF/SIF signal processing for CTVs and VC...
M52769FP is a semiconductor integrated circuit consisting of VIF/SIF signal processing for CTVs and VCRs. M52769FP corresponds to FM radio and provide low cost and high performance system with the coil-less AFT.
|
Symbol |
parameter |
Ratings |
Unit |
Note |
| Vcc | Supply Voltage 1 |
6.0 |
V |
|
| Pd | Power Consumption |
1190 |
mW |
|
| Topr | Operating Temperature |
-20to+75 |
||
| Tstg | Storage Temperatare |
-40to+150 |
M52769FP
PDF/DataSheet Download
M52768FP is a semiconductor integrated circuit consisting of VIF/SIF signal processing for CTVs and VCRs. M52768FP provide low cost and high performance system with the coil-less AFT.
The M52766FP is a semiconducttor IC with PLL system of VIF/ SIF.The circuit includes video UF amplifier,PLL video detector,IFAGC,RFAGC,VCO,AFT,LOCK DET,EQ,REG,QIFamplifier,QIF detector,QIF AGC,LIM,FM detector function.The M52766FP realize no abjustment SIF,n...
VIF amplification, Picture detection, APC detection, IF / RF AGC, VCO, AFT, Lock detection, Analog SW, SIF amplification, QIF amplification, QIF detection, QIF AGC, SIF limiter, FM detection.
The M52761 is IF signal-processing IC for VCRs and TVs. It enable the PLL detection system despite size as small as that of conventional quasi-synchronous VIF/SIF detector, IF/RF AGC, SIF limiter, FM detector, QIF AGC and EQ AMP.
The M52761 is IF signal-processing IC for VCRs and TVs. It enable the PLL detection system despite size as small as that of conventional quasi-synchronous VIF/SIF detector, IF/RF AGC, SIF limiter, FM detector, QIF AGC and EQ AMP.
The M52760SP is IF signal-processing IC for VCRs and TVs. It enable the PLL detection system despite size as small as that of conventional quasi-synchronous VIF/SIF detector, IF/RF AGC, SIF limiter, FM detector and EQ AMP.
