MFG:MIT Package Cooled:TSSOP/16
MFG: MIT
Package Cooled: TSSOP/16
Description: M52957AFP is a semiconductor integrated circuit containing distance detection signal processing circui...
M52957AFP is a semiconductor integrated circuit containing distance detection signal processing circuit for 3V supply voltage.
This device transforms each optical inflow current I1 and I2 from PSD SENSOR into the voltage, and integrates that output after doing calculation corresponds to I1/(I1+I2), and outputs it as the time data(pulse term).
| Parameter |
Symbol |
Ratings |
Unit |
Remark |
| Supply voltage |
VCC |
7.0 |
V |
note 1 |
| Power dissipation |
Pd |
320 |
mW |
Ta=25°C |
| Thermal derating |
K |
−3.2 |
mW/°C |
Ta25°C |
| Pin supply voltage |
VIF |
7.0 |
V |
Pin5, 7, 8, 9, 10, 11 |
| Another pin supply voltage |
VI/O |
−0.3 to VCC + 0.3 |
V |
note 2 |
| Output pin inflow current |
Isout |
0.5 |
mA |
NPN open collector |
| Operating temperature |
Topr |
−10 to 50 |
°C |
|
| Storage temperature |
Tstg |
−40 to 125 |
°C |
M52957AFP
