MFG:MITSUBISHI Package Cooled:SOP-20
MFG: MITSUBISHI
Package Cooled: SOP-20
Description: The M56710FP is a semiconductor integrated circuit of BiCMOS structure having an F2F demodulator funct...
The M56710FP is a semiconductor integrated circuit of BiCMOS structure having an F2F demodulator function for magnetic card reader.
|
Symbol |
Parameter |
Conditions |
Ratings |
Unit |
| Vcc | Supply voltage | VCC1,VCC2 |
-0.3to+6.5 |
V |
| VI | Input voltage | LDI,IB1,INV |
-0.3toVcc+0.3 |
V |
| VI | Intput voltage | HD1,HD2 |
-0.3toVcc+0.3 |
V |
| Io | Output voltage | CLS,RDT,RCP |
-10to+10 |
mA |
| VID | Differential input voltage | Between HD2 and HD1 pins |
-20to75 |
V |
| Topr | Operating temperature |
-20to+75 |
°C | |
| Tstg | Storage temperature |
-55to+125 |
Note 1: Voltage is based on GND pin of the circuit (0V), unless otherwise noted.
2: Direction of the current flowing into the circuit is represented by "positive" (without code) and that flowing out of the circuit by "negative" (- code).
M56710FP
