MFG:MIT Package Cooled:PDIP24 D/C:04+
MFG: MIT
Package Cooled: PDIP24
D/C: 04+
Description: The M62392P,FP is a CMOS 12-channel D-A converter with output buffer amplifiers.It can communi...
The M62392P,FP is a CMOS 12-channel D-A converter with output buffer amplifiers.
It can communicate with a microcontroller via few wiring thanks to the adoption of the two-line I2C BUS.
The output buffer amplifier employs AB class output with sinking and sourcing capability of more than 1.0mA , and an output voltage range is nearly between ground and VrefU.
Maximum 8 ICs can be connected to a bus by using three chip-select pins, so that it is possible to handle up to 96 channels.
|
Symbol |
Parameter |
conditions |
Ratings |
Unit |
|
VCC |
Supply voltage |
0.3 to 7.0 |
V | |
|
VDD |
Supply voltage |
0.3 to 7.0 |
V | |
|
VrefU1,2 |
DA converter HIGH level reference voltage |
0.3 to 7.0 |
V | |
|
Vin |
Input voltage |
0.3 toVDD+0.3 |
V | |
|
Vo |
Output voltage |
0.3 toVCC+0.3 |
V | |
|
Pd |
Power dissipation |
465(DIP) / 421(FP) |
mW | |
|
Topr |
Operating temperature |
-20 to +85 |
°C | |
|
Tstg |
Storage tempareture |
55 to 125 |
°C |
M62392P
