MFG:ST Package Cooled:DIP-16 D/C:200
MFG: ST
Package Cooled: DIP-16
D/C: 200
Description: The M7612 is a PIR ( passive infra-red ) controller , using analog mixing digital design technique and...
The M7612 is a PIR ( passive infra-red ) controller , using analog mixing digital design technique and manufactures by CMOS Process which can either drive TRIAC or RELAY depending on user's choice. With special noise immunity technique , M7612 is the most stable PIR controller you can find on the market. More than this , there are few components needed in its application circuit which can reduce material cost and increase competitive.
| Parameter | Sym. | Rating | Unit |
| Power Supply VDD With Respect to VSS | VDD - VSS | 5.6 | V |
| Voltage On Any Pin | -0.3 to 5.6 | V | |
| Operating Temperature | Top | -20 to 70 | |
| Storage Temperature | -65 to 150 |
M7612
PDF/DataSheet Download
