MFG:M/A-COM Package Cooled:N/A D/C:N/A
MFG: M/A-COM
Package Cooled: N/A
D/C: N/A
Description: The MA0S506AJ is a medium power 5.0 6.0 SPDT switch. Typical applications include the transmit/receiv...
The MA0S506AJ is a medium power 5.0 6.0 SPDT switch. Typical applications include the transmit/receive functions in 802.11a, Hiperlan, and fixed wireless access applications. All RF impedances are 50 ohms, and all RF ports are
internally DC blocked. The switch operates over a typical voltage range of 2.7 to 5.5 volts. The MA0S506AJ is offered in an MSOP-8 package.
The MA0S506AJ is fabricated using M/A-COM's 0.5 micron MESFET process for a low single supply voltage, high linearity, and excellent reliability.
| Parameter | Absolute Maximum |
| Max Input Power | + 33 dBm |
| Control Voltages | +8.0 volts |
| Supply Voltage | +8.0 volts |
| Operating Temperature | -40 to +100 |
| Channel Temperature | +150 |
| Storage Temperature | -40 to +150 |
1. Exceeding any one or combination of these limits may cause permanent damage.
• Ideal for 802.11a and Hiperlan Applications
• Positive Control Voltages
• +32 dB One dB Compression Point
• Fast Switching Speed
• No External Components Required
• MSOP-8 Package
MA0S506AJ
PDF/DataSheet Download
