MFG:Panasonic - SSG (VA)  Category:Discrete Semiconductor Products

MA3XD1100L

MA3 Series Datasheet download

Five Points

Part Number: MA3XD1100L

Category: Discrete Semiconductor Products

MFG: Panasonic - SSG (VA)





Descriptions: DIODE SCHOTTKY 20V 1A MINI 3P

Price Break

1
10
100
500
1000

Unit Price

.59000
.47200
.35410
.19594
.16526

Extended Price

0.59
4.72
35.41
97.97
165.26

(All prices are in USD) Prices for reference only
Urgent Purchase

MA3XD1100L General Description

DIODE SCHOTTKY 20V 1A MINI 3P

MA3XD1100L Parameters

Technical/Catalog InformationMA3XD1100L
VendorPanasonic - SSG (VA)
CategoryDiscrete Semiconductor Products
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max)20V
Current - Average Rectified (Io)1A
Voltage - Forward (Vf) (Max) @ If450mV @ 1A
Reverse Recovery Time (trr)-
Current - Reverse Leakage @ Vr200A @ 20V
SpeedFast Recovery =< 500ns, > 200mA (Io)
Mounting TypeSurface Mount
Package / CaseMini 3P
PackagingCut Tape (CT)
Capacitance @ Vr, F180pF @ 0V, 1MHz
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MA3XD1100L
MA3XD1100L
MA3XD1100LCT ND
MA3XD1100LCTND
MA3XD1100LCT
