Part Number: MA4X796











Urgent Purchase

MA4X796 Maximum Ratings

Parameter Symbol Rating Unit
Reverse voltage (DC)
 VR 50 V
Repetitive peak reverse voltage VRM 50 V
Peak forward
current		 Single IF 300 mA
Double*2 200
Average forward
current		 Single IFM 100 mA
Double*2 70
Non-repetitive pea
forward surge current*		 IFSM 1 mA
Junction temperature Tj 125 °C
Storage temperature Tstg −55 to +150 °C
Note) *1 : The peak-to-peak value in one cycle of 50 Hz sine-wave (non-repetitive)
*2 : Value per chip

MA4X796 Features

• Two MA3X787s in the same direction are contained in one package
• Allowing to rectify under (IF(AV) = 100 mA) condition
• Optimum for high-frequency rectification because of its short reverse recovery time (trr)
• Low VF (forward rise voltage), with high rectification efficiency
• Reverse voltage VR (DC value) = 50 V guaranteed

MA4X796 datasheet

MA4X796
PDF/DataSheet Download

  • Datasheet: MA4X796
  • File Size: 51026 KB
  • Manufacturer: PANASONIC [Panasonic Semiconductor]
  • Click here to Download
