Position: Home > Datasheet list > MA4 Series > Index M > MA4ZD0300L
Electronica China

Purchase MA4ZD0300L, In-stock MA4ZD0300L From SeekIC.

MFG:Panasonic - SSG (VA)  Category:Discrete Semiconductor Products

MA4ZD0300L

MA4 Series Datasheet download

Five Points

Part Number: MA4ZD0300L

Category: Discrete Semiconductor Products

MFG: Panasonic - SSG (VA)





Descriptions: DIODE SCHOTTKY 45V 75MA S-MINI4P

Price Break

1
10
100
500
1000

Unit Price

.50000
.37600
.28220
.17558
.16681

Extended Price

0.50
3.76
28.22
87.79
166.81

(All prices are in USD) Prices for reference only
Urgent Purchase

MA4ZD0300L General Description

DIODE SCHOTTKY 45V 75MA S-MINI4P

MA4ZD0300L Parameters

Technical/Catalog InformationMA4ZD0300L
VendorPanasonic - SSG (VA)
CategoryDiscrete Semiconductor Products
Diode Type Schottky
Diode Configuration2 Independent
Voltage - DC Reverse (Vr) (Max)45V
Current - Average Rectified (Io) (per Diode)100mA (DC)
Voltage - Forward (Vf) (Max) @ If600mV @ 100mA
Current - Reverse Leakage @ Vr5A @ 40V
Reverse Recovery Time (trr)1.2ns
SpeedSmall Signal =< 200mA (Io), Any Speed
Mounting TypeSurface Mount
Package / CaseS-Mini 4P
PackagingCut Tape (CT)
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MA4ZD0300L
MA4ZD0300L
MA4ZD0300LCT ND
MA4ZD0300LCTND
MA4ZD0300LCT

MA4ZD0300L datasheet

MA4000
PDF/DataSheet Download
