MA6X12500L

DIODE SWITCH 40V 100MA MINI 6P

product image

MA6X12500L Picture
See larger image
SeekIC No. : 003426892 Detail

MA6X12500L: DIODE SWITCH 40V 100MA MINI 6P

MA6X12500L Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MA6X12500L
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2026/3/31

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: - Manufacturer: Panasonic Electronic Components - Semiconductor Products
Voltage - Forward (Vf) (Max) @ If: 1.2V @ 100mA Current - Reverse Leakage @ Vr: 100nA @ 40V
Current - Average Rectified (Io) (per Diode): 100mA (DC) Drain Source Voltage VDS : 15 V
Voltage - DC Reverse (Vr) (Max): 40V Reverse Recovery Time (trr): 150ns
Diode Type: Standard Speed: Small Signal =< 200mA (Io), Any Speed
Diode Configuration: 2 Pair Series Connection Mounting Type: Surface Mount
Package / Case: SOT-23-6 Supplier Device Package: MINI6-G1

Description

Series: -
Diode Type: Standard
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Voltage - DC Reverse (Vr) (Max): 40V
Packaging: Tape & Reel (TR)
Voltage - Forward (Vf) (Max) @ If: 1.2V @ 100mA
Diode Configuration: 2 Pair Series Connection
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Current - Average Rectified (Io) (per Diode): 100mA (DC)
Package / Case: SOT-23-6
Supplier Device Package: MINI6-G1
Reverse Recovery Time (trr): 150ns
Current - Reverse Leakage @ Vr: 100nA @ 40V


Parameters:

Technical/Catalog InformationMA6X12500L
VendorPanasonic - SSG
CategoryDiscrete Semiconductor Products
Diode Type Standard
Diode Configuration2 Pair Series Connection
Voltage - DC Reverse (Vr) (Max)40V
Current - Average Rectified (Io) (per Diode)100mA (DC)
Voltage - Forward (Vf) (Max) @ If1.2V @ 100mA
Current - Reverse Leakage @ Vr100nA @ 75V
Reverse Recovery Time (trr)150ns
SpeedSmall Signal =< 200mA (Io), Any Speed
Mounting TypeSurface Mount
Package / CaseMini 6P
PackagingTape & Reel (TR)
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MA6X12500L
MA6X12500L
MA6X12500LTR ND
MA6X12500LTRND
MA6X12500LTR
