MFG:Maxim Package Cooled:SOP/DIP D/C:06+
MFG: Maxim
Package Cooled: SOP/DIP
D/C: 06+
Description: The MAX4322/MAX4323/MAX4326/MAX4327/MAX4329 family of operational amplifiers combines wide bandwidth and ...
The MAX4322/MAX4323/MAX4326/MAX4327/MAX4329 family of operational amplifiers combines wide bandwidth and excellent DC accuracy with Rail-to-Rail® operation at the inputs and outputs. These devices require only 650µA per amplifier and operate from either a single supply (+2.4V to +6.5V) or dual supplies (±1.2V to ±3.25V). These unity gain-stable amplifiers are capable of driving 250Ω loads and have a 5MHz gain-bandwidth product. The MAX4323 and MAX4327 feature a low-power shutdown mode that reduces supply current to 25µA and places the outputs in a high impedance state.
With their rail-to-rail input common-mode range and output swing, these amplifiers are ideal for low-voltage, single supply operation. In addition, low offset voltage and high speed make them the ideal signal-conditioning stages for precision, low-voltage data-acquisition systems. The MAX4322/MAX4323 are available in space-saving SOT23 packages.
Supply Voltage (VCC-VEE) ......................................................+7.5V
All Other Pins .......................................(VCC + 0.3V) to (VEE - 0.3V)
Output Short-Circuit Duration....Continuous (short to either supply)
Continuous Power Dissipation (TA = +70°C)
5-pin SOT23-5 (derate 7.1mW/°C above +70°C) ..............571mW
6-pin SOT23 (derate 7.1mW/°C Above + 70°C) ................571mW
8-pin SO (derate 5.88mW/°C above +70°C)......................471mW
8-pin µMAX (derate 4.10mW/°C above +70°C) .................330mW
10-pin µMAX (derate 5.6mW/°C above +70°C) .................444mW
14-pin SO (derate 8.00mW/°C above +70°C)....................640mW
Operating Temperature Range
MAX432_E__ .........................................................-40°C to +85°C
Maximum Junction Temperature ..........................................+150°C
Storage Temperature Range ...............................-65°C to +160°C
Lead Temperature (soldering, 10sec) .................................+300°C
MAX4322
PDF/DataSheet Download
IC OPAMP 5MHZ R-TO-R I/O SOT23-5
IC OP AMP R-R I/O LV SOT23-5
