MB356
-
Suppliers
DataSheet
General Description
MB356 Maximum Ratings
Rating 25 ambient temperature uniess otherwies specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
| TYPE NUMBER | MB3505 | MB351 | MB352 | MB354 | MB356 | MB358 | MB3510 | UNITS | |
| Maximum Recurrent Peak Reverse Voltage | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | V | |
| Maximum RMS Voltage | 35 | 70 | 140 | 280 | 420 | 560 | 700 | V | |
| Maximum DC Blocking Voltage | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | V | |
| Maximum Average Forward Rectified Current | A | ||||||||
| .375"(9.5mm) Lead Length at Tc=55 |
35 |
||||||||
| Peak Forward Surge Current, 8.3 ms single half sine-wave | A | ||||||||
| superimposed on rated load (JEDEC method) |
400 |
||||||||
| Maximum Forward Voltage Drop per Bridge Element at 17.5AD.C. |
1.1 |
V | |||||||
| Maximum DC Reverse Current | Ta=25 |
10 |
A | ||||||
| at Rated DC Blocking Voltage | Ta=100 |
500 |
A | ||||||
| Operating Temperature Range, TJ |
-65- +125 |
||||||||
| Storage Temperature Range, TSTG |
-65- +150 |
||||||||
MB356 Features
* 400 amperes surge capability
* Superior thermal design
* Mounting: Hole thru for #8 screw
* 1/4" universal faston terminal
* Superior thermal design
* Mounting: Hole thru for #8 screw
* 1/4" universal faston terminal
