MB88346B-PFV

The MB88346B is an R-2R type 8-bit resolution digital-to-analog converter(DAC),designed for interface with a wide range of general 4 bit and 8 bit microcontrollers.The MB88346B-PFV belongs to MB88346B series.

The absolute maximum ratings of the MB88346B-PFV can be summarized as:(1):the parameter is supply voltage,the symbol is Vcc,the Min is -0.3,the Max is 7.0,the unit is V,the condition is Ta=+25 GND=0V VDDVCC;(2):the parameter is supply voltage,the symbol is VDD,the Min is -0.3,the Max is 7.0,the unit is V,the condition is Ta=+25 GND=0V VDDVCC;(3):the parameter is input voltage,the symbol is VIN,the Min is -0.3,the Max is VCC+0.3,the unit is V,the condition is Ta=+25 GND=0V;(4):the parameter is output voltage,the symbol is VOUTc,the Min is -0.3,the Max is VCC+0.3,the unit is V,the condition is Ta=+25 GND=0V;(5):the parameter is power dissipation,the symbol is PD,the Max is 250,the unit is mW;(6):the parameter is operating ambient temperature,the symbol is Ta,the Min is -20,the Max is +85,the unit is ;(7):the parameter is storage ambient temperature,the symbol is Tstg,the Min is -55,the Max is +150,the unit is .
