Purchase MBR15100, In-stock MBR15100 From SeekIC.
MFG:TO-220AC Package Cooled:11650 D/C:Microsemi
- Table of contents:
MBR15100
-
Suppliers
DataSheet
General Description
MBR15100 Maximum Ratings
· Operating Temperature: -55°C to +150°C
· Storage Temperature: -55°C to +175°C
· Storage Temperature: -55°C to +175°C
| Microsemi Catalog Number |
Device Marking |
Maximum Recurrent Peak Reverse Voltage |
Maximum RMS Voltage |
Maximum DC Blocking Voltage |
| MBR1520 | MBR1520 | 20V | 14V | 20V |
| MBR1530 | MBR1530 | 30V | 21V | 30V |
| MBR1535 | MBR1535 | 35V | 24.5V | 35V |
| MBR1540 | MBR1540 | 40V | 28V | 40V |
| MBR1545 | MBR1545 | 45V | 31.5V | 45V |
| MBR1560 | MBR1560 | 60V | 42V | 60V |
| MBR1580 | MBR1580 | 80V | 56V | 80V |
| MBR15100 | MBR15100 | 100V | 70V | 100V |
MBR15100 Features
· Metal of siliconrectifier, majonty carrier conducton
· Guard ring for transient protection
· Low power loss high efficiency
· High surge capacity, High current capability
· Guard ring for transient protection
· Low power loss high efficiency
· High surge capacity, High current capability
MBR15100
PDF/DataSheet Download
- Datasheet: MBR15100
- File Size: 83431 KB
- Manufacturer: MCC [Micro Commercial Components]
- Click here to Download
