MBR20200CTTU, US $ .5-.72 , Fairchild Semiconductor, MBR20200CTTU DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 00185248 Detail

MBR20200CTTU: Schottky (Diodes & Rectifiers) Dual High Voltage

MBR20200CTTU Data Sheet

US $ .5~.72 / Piece | Get Latest Price

Part Number:: MBR20200CTTU
Mfg:: Fairchild Semiconductor
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~250

Unit Price
$.72
$.63
$.58
$.5

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

MBR20...CT evaluate
Features: 150° C TJ operationCenter tap TO-220, D2Pak and TO-262 packagesLow forward voltage dropH...
MBR20...CT-1 evaluate
Features: 150° C TJ operationCenter tap TO-220, D2Pak and TO-262 packagesLow forward voltage dropH...
MBR20..CT Series evaluate
DescriptionSchottky Rectifier, 2 x 10 A MBR20..CT Series

Product Details

Quick Details

Product :	Schottky Diodes	Peak Reverse Voltage :	200 V
Forward Continuous Current :	20 A	Max Surge Current :	150 A
Configuration :	Dual Common Cathode	Forward Voltage Drop :	1 V
Maximum Reverse Leakage Current :	200 uA	Operating Temperature Range :	+ 150 C
Mounting Style :	Through Hole	Package / Case :	TO-220AB
Packaging :	Tube

Description

Recovery Time :
Maximum Power Dissipation :
Mounting Style : Through Hole
Product : Schottky Diodes
Forward Voltage Drop : 1 V
Packaging : Tube
Maximum Reverse Leakage Current : 200 uA
Package / Case : TO-220AB
Forward Continuous Current : 20 A
Peak Reverse Voltage : 200 V
Configuration : Dual Common Cathode
Max Surge Current : 150 A
Operating Temperature Range : + 150 C

Parameters:

Technical/Catalog Information	MBR20200CTTU
Vendor	Fairchild Semiconductor
Category	Discrete Semiconductor Products
Diode Type	Schottky
Diode Configuration	1 Pair Common Cathode
Voltage - DC Reverse (Vr) (Max)	200V
Current - Average Rectified (Io) (per Diode)	10A
Voltage - Forward (Vf) (Max) @ If	900mV @ 10A
Current - Reverse Leakage @ Vr	200A @ 200V
Reverse Recovery Time (trr)	-
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Mounting Type	Through Hole, Radial
Package / Case	TO-220
Packaging	Tube
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MBR20200CTTU MBR20200CTTU
