Purchase MC34063A, In-stock MC34063A From SeekIC.
Package Cooled:SMD-8
Part Number: MC34063A
Package Cooled: SMD-8
Description: The MC34063A series is a monolithic control circuit delivering the main functions for DC-DC voltage co...
- Table of contents:
MC34063A
-
Suppliers
DataSheet
General Description
MC34063A General Description
The MC34063A series is a monolithic control circuit delivering the main functions for DC-DC voltage converting.
The device contains an internal temperature compensated reference, comparator, duty cycle controlled oscillator with an active current limit circuit, driver and high current output switch.
Output voltage is adjustable through two external resistors with a 2% reference accuracy.
Employing a minimum number of external components the MC34063A devices series is designed for Step-Down, Step-Up and Voltage-Invertingapplications.
MC34063A Maximum Ratings
| Symbol | Parameter | Value | Unit |
| VCC | Power Supply Voltage | 50 | V |
| Vir | Comparator Input Voltage Range | -0.3 to 40 | V |
| VSWC | Switch Collector Voltage | 40 | V |
| VSWE | Switch Emitter Voltage (VSWC = 40V) | 40 | V |
| VCE | Switch Emitter to Collector Voltage | 40 | V |
| Vdc | Driver Collector Voltage | 40 | V |
| Idc | Driver Collector Current | 100 | mA |
| ISW | Switch Current | 1.5 | A |
| Ptot | Power Dissipation at Tamb = 25 (forPlasticPackage) (for SOIC Package) |
1.25 0.625 |
W |
| Top | Operating Ambient Temperature Range (for AC SERIES) (for AB SERIES) |
0 to 70 - 40 to 85 |
|
| Tstg | Storage Temperature Range | - 40 to 150 |
MC34063A Features
The MC34063A series is a monolithic control circuit
delivering the main functions for DC-DC voltage
converting. The device contains an internal temperature
compensated reference, comparator, duty cycle controlled
oscillator with an active current limit circuit, driver and
high current output switch. Output voltage is adjustable
through two external resistors with a 2% reference accuracy.
Employing a minimum number of external components the MC34063A
devices series is designed for Step-Down, Step-Up and Voltage-
Invertingapplications.
MC34063A
PDF/DataSheet Download
- Datasheet: MC34063A
- File Size: 799672 KB
- Manufacturer: TI [Texas Instruments]
- Click here to Download
