MC74HC132A Product Image

MC7 Series Datasheet download

Five Points

Part Number: MC74HC132A



MFG: 101

Package Cooled: ON



Description: The MC74HC132A is identical in pinout to the LS132. The device inputs are compatible with standard CMOS outputs; with p...


Urgent Purchase

MC74HC132A General Description


The MC74HC132A is identical in pinout to the LS132. The device inputs are compatible with standard CMOS outputs; with pullup resistors, they are compatible with LSTTL outputs.

The HC132A can be used to enhance noise immunity or to square up slowly changing waveforms.

MC74HC132A Maximum Ratings

Symbol Parameter Value Unit
VCC DC Supply Voltage 0.5 to + 7.0 v
Vin DC Input Voltage 0.5 to + 7.0 V
Vout DC Output Voltage 0.5 to VCC + 0.5 v
Iin DC Input Current ,per Pin 20 mA
Iout DC Output Current, per Pin ± 25 mA
Icc DC Supply Current, VCC and GND Pins ±50 mA
PD Power Dissipation in Still Air,Plastic DIP


                                      SOIC Package

750

500 		mw
Tstg Storage Temperature 65 to + 150
TL Lead Temperature,1 mm from Case for 10 seconds
(Plastic DIP,SOIC or Tssop Package ) 		260


<

MC74HC132A Features

• Output Drive Capability: 10 LSTTL Loads
• Outputs Directly Interface to CMOS, NMOS, and TTL
• Operating Voltage Range: 2.0 to 6.0 V
• Low Input Current: 1.0 A
• High Noise Immunity Characteristic of CMOS Devices
• In Compliance with the Requirements Defined by JEDEC Standard No. 7A
• Chip Complexity: 72 FETs or 18 Equivalent Gates

MC74HC132A Connection Diagram

MC74HC132A Connection Diagram
