General Description
MCC 170 Maximum Ratings
|
ITRMS |
TVJ = TVJM |
350 203 |
A A | |
|
ITSM |
TVJ = 45°C; VR = 0 |
t = 10 ms (50 Hz), sine t = 8.3 ms (60 Hz), sine |
5400 5800 |
A A |
|
TVJ = TVJM VR = 0 |
t = 10 ms (50 Hz), sine t = 8.3 ms (60 Hz), sine |
5000 5500 |
A A | |
|
i2dt |
TVJ = 45°C VR = 0 |
t = 10 ms (50 Hz), sine t = 8.3 ms (60 Hz), sine |
146000 140000 |
A2s A2s |
|
TVJ = TVJM VR = 0 |
t = 10 ms (50 Hz), sine t = 8.3 ms (60 Hz), sine |
125000 126000 |
A2s A2s | |
|
(di/dt)cr |
TVJ = TVJM f =50 Hz, tP =200 s VD = 2/3 VDRM IG = 0.45 A diG/dt = 0.45 A/s |
repetitive, IT = 45 A |
100 |
A/s |
|
non repetitive, IT = ITAVM |
500 |
A/s | ||
|
(dv/dt)cr |
TVJ = TVJM; RGK = ; method 1 |
VDR = 2/3 VDRM (linear voltage rise) |
1000 |
V/s |
|
PGM |
TVJ = TVJM IT = ITAVM |
tP = 30 s tP = 300 s |
120 60 20 10 |
W W W V |
|
VRGM |
10 |
V | ||
|
TVJ TVJM Tstg |
-40...+125 125 -40...+125 |
°C °C °C | ||
|
VISOL |
50/60 Hz, RMS IISOL 1 mA |
t = 1 min |
3000 3600 |
V~ V~ |
|
Md Weight |
Mounting torque (M5) Terminal connection torque (M5) Typical including screws |
2.5-4.0/22-35 2.5-4.0/22-35 750 |
Nm/lb.in. Nm/lb.in. g |
MCC 170 Features
· International standard package
· Direct copper bonded Al2O3-ceramic with copper base plate
· Planar passivated chips
· Isolation voltage 3600 V~
· UL registered E 72873
· Keyed gate/cathode twin pins
· Direct copper bonded Al2O3-ceramic with copper base plate
· Planar passivated chips
· Isolation voltage 3600 V~
· UL registered E 72873
· Keyed gate/cathode twin pins
MCC 170 Typical Application
· Motor control, softstarter
· Power converter
· Heat and temperature control for industrial furnaces and chemical processes
· Lighting control
· Solid state switches
