Purchase MCF52256CAG66, In-stock MCF52256CAG66 From SeekIC.

MFG:Freescale Semiconductor  Category:Integrated Circuits (ICs)

MCF52256CAG66

MCF Series Datasheet download

Five Points

Part Number: MCF52256CAG66

Category: Integrated Circuits (ICs)

MFG: Freescale Semiconductor





Descriptions: MCU 32BIT COLDFIRE V2 144LQFP

Price Break

1
25
100

Unit Price

7.51000
6.28360
5.64480

Extended Price

7.51
157.09
564.48

(All prices are in USD) Prices for reference only
Urgent Purchase

MCF52256CAG66 General Description

MCU 32BIT COLDFIRE V2 144LQFP

MCF52256CAG66 Parameters

Technical/Catalog InformationMCF52256CAG66
VendorFreescale Semiconductor
CategoryIntegrated Circuits (ICs)
Program Memory Size256K x 8
RAM Size64K x 8
Number of I /O96
Package / Case144-LQFP
Speed66MHz
Controller SeriesMCF5225x
Oscillator TypeInternal
PackagingTray
Program Memory TypeFLASH
EEPROM Size-
Core ProcessorColdfire V2
Data ConvertersA/D 8x12b
Core Size32-Bit
Operating Temperature-40°C ~ 85°C
ConnectivityCAN, EBI/EMI, Ethernet, I²C, QSPI, UART/USART, USB
PeripheralsDMA, LVD, POR, PWM, WDT
Voltage - Supply (Vcc/Vdd)3 V ~ 3.6 V
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MCF52256CAG66
MCF52256CAG66

MCF52256CAG66 datasheet

MCF5202
PDF/DataSheet Download
