Purchase MCF52258AG80, In-stock MCF52258AG80 From SeekIC.

MFG:Freescale Semiconductor  Category:Integrated Circuits (ICs)

MCF52258AG80

MCF Series Datasheet download

Five Points

Part Number: MCF52258AG80

Category: Integrated Circuits (ICs)

MFG: Freescale Semiconductor





Descriptions: MCU 64BIT COLDFIRE V2 144LQFP

Price Break

1
25
100

Unit Price

8.14000
6.81280
6.12000

Extended Price

8.14
170.32
612.00

(All prices are in USD) Prices for reference only
Urgent Purchase

MCF52258AG80 General Description

MCU 64BIT COLDFIRE V2 144LQFP

MCF52258AG80 Parameters

Technical/Catalog InformationMCF52258AG80
VendorFreescale Semiconductor
CategoryIntegrated Circuits (ICs)
Program Memory Size512KB (512K x 8)
RAM Size64K x 8
Number of I /O96
Package / Case144-LQFP
Speed80MHz
Controller SeriesMCF5225x
Oscillator TypeInternal
PackagingTray
Program Memory TypeFLASH
EEPROM Size-
Core ProcessorColdfire V2
Data ConvertersA/D 8x12b
Core Size32-Bit
Operating Temperature0°C ~ 70°C
ConnectivityCAN, EBI/EMI, Ethernet, I²C, QSPI, UART/USART, USB
PeripheralsDMA, LVD, POR, PWM, WDT
Voltage - Supply (Vcc/Vdd)3 V ~ 3.6 V
Drawing Number375; 918-03; ; 144
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MCF52258AG80
MCF52258AG80
