MCP3202

Specifications

Parameter Name	Value
Max Sample Rate (ksamples/sec)	100
Max. INL ± (LSB)	1
Max. Supply Current (A)	550
Input Type	Single-ended
# of Input Channels	2
Resolution (bits)	12
Interface	SPI
Temp Range (°C)	-40 to +85°C
Input Voltage Range (V)	2.7 to 5.5

Description

The MCP3202 12-bit Analog-to-Digital Converter (ADC) combines high performance and low power consumption in a small package, making it ideal for embedded control applications. The MCP3202 features a successive approximation register (SAR) architecture and an industry-standard SPI? serial interface, allowing 12-bit ADC capability to be added to any PICmicro? microcontroller. The MCP3202 features 100k samples/second, 2 input channels, low power consumption (5nA typical standby, 550 A max. active), and is available in 8-pin PDIP, SOIC and TSSOP packages. Applications for the MCP3202 include data acquisition, instrumentation and measurement, multi-channel data loggers, industrial PCs, motor control, robotics, industrial automation, smart sensors, portable instrumentation and home medical appliances.
