MD27C64-35B

The MD27C64-35B belongs to the AM27C64 family which designed as one kind of ultraviolet erasable programmable read-only memory. This device has a static standby mode, and features fast single address location programming and is organized as 8K words by 8 bits per word, operates from a single +5 V supply. Also it can be used in windowed ceramic DIP packages as well as plastic one time programmable (OTP) PDIP, and PLCC packages.

Features of the MD27C64-35B are:(1)standard 28-pin DIP, PDIP, and 32-pin PLCC packages;(2)cersatile features for simple interfacing:both CMOS and TTL input/output compatibility and two line control functions;(3)high noise immunity;(4)latch-up protected to 100 mA from -1 V to Vcc+1 V;(5)100 % flashriteTM programming:typical programming time of 1 second;(6)±10% power supply tolerance available;(7)single +5 V power supply;(8)JEDEC-approved pinout;(9)low power consumption:20 mA typical CMOS standby current;(10)fast access time:45 ns.

The absolute maximum ratings of the MD27C64-35B can be summarized as:(1)storage temperature OTP products:-65°C to +125°C;(2)storage temperature all other products:-65°C to +150°C;(3)ambient temperature with power applied:-55°C to +125°C;(4)voltage with respect to Vss (all pins except A9,Vpp, Vcc):-0.6 V to Vcc+0.5 V;(5)voltage with respect to Vss (A9 and VPP):-0.6 V to +13.5 V;(6)voltage with respect to Vss:-0.6 V to +7.0 V. If you want to know more information such as the electrical characteristics about it, please download the datasheet in www.seekic.com or www.chinaicmart.com .
