Part Number: MDA 72











Urgent Purchase

MDA 72 Maximum Ratings

ITRMS
ITAVM

TVJ = TVJM
TC = 58°C; 180° sine
TC = 100°C; 180° sine
180
113
99
A
A
ITSM
TVJ = 45°C;
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
1700
1950
A
A
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
1540
1800
A
A
i2dt
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
14450
15700
A2s
A2s
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
11850
13400
A2s
A2s
TVJ
TVJM
Tstg
-40...+150
150
-40...+125
°C
°C
°C
VISOL
50/60 Hz, RMS
IISOL 1 mA

t = 1 min
t = 1 s
3000
3600
V~
V~

Md

Weight
Mounting torque (M5)
Terminal connection torque (M5)
Typical including screws
2.5-4.0/22-35
2.5-4.0/22-35
90
Nm/lb.in.
Nm/lb.in.
g

MDA 72 Features

· International standard package JEDEC TO-240 AA
· Direct copper bonded Al2O3 -ceramic base plate
· Planar passivated chips
· Isolation voltage 3600 V~
· UL registered, E 72873

MDA 72 Typical Application

· Supplies for DC power equipment
· DC supply for PWM inverter
· Field supply for DC motors
· Battery DC power supplies
