Purchase MEK 150-04 DA, In-stock MEK 150-04 DA From SeekIC.
- Table of contents:
MEK 150-04 DA
-
Suppliers
DataSheet
General Description
MEK 150-04 DA Maximum Ratings
|
I FRMS IFAVM |
TC = 100; rectangular, d = 0.5 |
200 150 |
A A |
|
IFSM |
TVJ = 45; t = 10 ms (50 Hz), sine |
1200 |
A |
|
TVJ TVJM Tstg |
-40...+150 175 -40...+150 |
| |
|
Ptot |
TC = 25 |
360 |
W |
|
VISOL |
50/60 Hz, RMS; IISOL 1 mA |
3600 |
V~ |
|
Md |
Mounting torque with screw M5 Terminal connection torque |
2.5-4/22-35 2.5-4/22-35 |
Nm/lb.in. Nm/lb.in. |
|
Weight |
typical |
90 |
g |
MEK 150-04 DA Features
· International standard package with DCB ceramic base plate
· Planar passivated chips
· Short recovery time
· Low switching losses
· Soft recovery behaviour
· Isolation voltage 3600 V~
· UL registered E 72873
· Planar passivated chips
· Short recovery time
· Low switching losses
· Soft recovery behaviour
· Isolation voltage 3600 V~
· UL registered E 72873
MEK 150-04 DA Typical Application
· Antiparallel diode for high frequency switching devices
· Free wheeling diode in converters and motor control circuits
· Inductive heating and melting
· Uninterruptible power supplies (UPS)
· Ultrasonic cleaners and welders
· Free wheeling diode in converters and motor control circuits
· Inductive heating and melting
· Uninterruptible power supplies (UPS)
· Ultrasonic cleaners and welders
MEK150-04DA
PDF/DataSheet Download
- Datasheet: MEK150-04DA
- File Size: 29935 KB
- Manufacturer: IXYS [IXYS Corporation]
- Click here to Download
