General Description
MJ14001/D Maximum Ratings
|
Rating |
Symbol |
MJ14001 |
MJ14002 MJ14003 |
Unit |
| CollectorEmitter Voltage |
VCEO |
60 |
80 |
VDC |
| Collector Base Voltage |
VCBO |
60 |
80 |
VDC |
| EmitterBase Voltage |
VEBO |
5 |
VDC | |
| Collector Current - Continuous |
IC |
60 |
ADC | |
| Base Current - Continuous |
IB |
15 |
ADC | |
| Emitter Current - Continuous |
IE |
75 |
||
| Total Power Dissipation @ TC = 25 Derate above 25C |
PD |
300 17 |
Watts W/ | |
| Operating and Storage Junction Temperature Range |
TJ, Tstg |
65 to +200 |
||
MJ14001/D Typical Application
• High Current Capability - IC Continuous = 60 Amperes
• DC Current Gain - hFE = 15100 @ IC = 50 Adc
• Low CollectorEmitter Saturation Voltage - VCE(sat) = 2.5 Vdc (Max) @ IC = 50 Adc
• DC Current Gain - hFE = 15100 @ IC = 50 Adc
• Low CollectorEmitter Saturation Voltage - VCE(sat) = 2.5 Vdc (Max) @ IC = 50 Adc
