MFG:ON Semiconductor  Category:Discrete Semiconductor Products

MJ2955G

MJ2 Series Datasheet download

Five Points

Part Number: MJ2955G

Category: Discrete Semiconductor Products

MFG: ON Semiconductor





Descriptions: TRANS PNP 15A 60V TO-3

Price Break

1
10
100
250
500
1000
2500
5000

Unit Price

2.98000
2.78200
2.28530
1.88784
1.58976
1.36620
1.29168
1.26684

Extended Price

2.98
27.82
228.53
471.96
794.88
1366.20
3229.20
6334.20

(All prices are in USD) Prices for reference only
Urgent Purchase

MJ2955G General Description

TRANS PNP 15A 60V TO-3

MJ2955G Parameters

Technical/Catalog InformationMJ2955G
VendorON Semiconductor
CategoryDiscrete Semiconductor Products
Transistor TypePNP
Voltage - Collector Emitter Breakdown (Max)60V
Current - Collector (Ic) (Max)15A
Power - Max115W
DC Current Gain (hFE) (Min) @ Ic, Vce20 @ 4A, 4V
Vce Saturation (Max) @ Ib, Ic1.1V @ 400mA, 4A
Frequency - Transition2.5MHz
Current - Collector Cutoff (Max)700A
Mounting TypeChassis Mount
Package / CaseTO-204, TO-3
PackagingTray
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MJ2955G
MJ2955G
MJ2955GOS ND
MJ2955GOSND
MJ2955GOS
