Purchase MM1278, In-stock MM1278 From SeekIC.
D/C:1450
- Table of contents:
MM1278
-
Suppliers
DataSheet
General Description
MM1278 Maximum Ratings
|
Item |
SYMBOL |
Rating |
UNIT |
|
Storage temperature Operating temperature Power supply voltage Input voltage Allowable power dissipation |
TSTG TOPR VCC max. VIN Pd |
-40~+125 -20~+75 -0.3~+10 -0.3~+10 300 |
°C °C V V mW |
MM1278 Features
General
1. Power supply voltage VCC=1.8V~6V
optimum for drive by batteries
2. Current consumption 0.1mA typ.
3. Power supply line elimination ratio 60dB typ.
Amplifier section
1. Input voltage range -0.2V~+0.3V
2. Super low input offset voltage ±0.1mV typ.
3. Input offset voltage ±1µV/°C typ.
4. Input offset current 1nA typ.
5. Input bias current 50nA typ.
6. Gain 100dB typ.
1. Power supply voltage VCC=1.8V~6V
optimum for drive by batteries
2. Current consumption 0.1mA typ.
3. Power supply line elimination ratio 60dB typ.
Amplifier section
1. Input voltage range -0.2V~+0.3V
2. Super low input offset voltage ±0.1mV typ.
3. Input offset voltage ±1µV/°C typ.
4. Input offset current 1nA typ.
5. Input bias current 50nA typ.
6. Gain 100dB typ.
MM1278 Typical Application
1. Amplification and detection of normal very small voltage on portable equipment.
2. Amplification of very small voltage for sensors (thermocouples, strain gauges, magnetic sensors)
3. Detedtion of very small current
2. Amplification of very small voltage for sensors (thermocouples, strain gauges, magnetic sensors)
3. Detedtion of very small current
MM1278
PDF/DataSheet Download
- Datasheet: MM1278
- File Size: 64249 KB
- Manufacturer: MITSUMI [Mitsumi Electronics, Corp.]
- Click here to Download
- ·MM1002
- MITSUMI [Mitsumi Electronics, Corp.]
- Video Amplifier
- 106919 KB
- ·MM1002F
- MITSUMI [Mitsumi Electronics, Corp.]
- Video Amplifier
- 106919 KB
- ·MM1006
- MITSUBISHI [Mitsubishi Electric Semiconductor]
- Monolithic IC MM1006
- 119479 KB
- ·MM1007
- Mitsumi
- HBS-Compatible Driver and Receiver
- 135434 KB
- ·MM100E164
- 16:1 MULTIPLEXER
- 100639 KB
- ·MM100E166
- 9-BIT MAGNITUDE COMPARATOR
- 99401 KB
- ·MM100E167
- 6-BIT 2:1MUX-REGISTER
- 108521 KB
- ·MM100E211
- 1:6 DIFFERENTIAL CLOCK DISTRIBUTION CHIP
- 125965 KB
MM1278 Relative Products
MM1270
MM1268
MM126036
