MFG:FSC Package Cooled:DIP, SOIC-Wide D/C:08+
MFG: FSC
Package Cooled: DIP, SOIC-Wide
D/C: 08+
Description: The MM74C240 and MM74C244 octal buffers and line drivers are monolithic complementary MOS (CMOS) integ...
The MM74C240 and MM74C244 octal buffers and line drivers are monolithic complementary MOS (CMOS) integrated circuits with 3-STATE outputs. These outputs have been specially designed to drive highly capacitive loads such as bus-oriented systems. These devices have a fan out of 6 low power Schottky loads. A high logic level on the output disable control input G makes the outputs go into the high impedance state.
| Voltage at Any Pin |
-0.3V to VCC + 0.3V |
| Operating Temperature Range |
-40 to +85 |
| Storage Temperature Range |
-65 to +150 |
| Power Dissipation | |
| Dual-In-Line |
700 mW |
| Small Outline |
500 mW |
| Operating VCC Range |
3V to 15V |
| Absolute Maximum VCC |
18V |
| Lead Temperature | |
| (Soldering, 10 seconds) |
260 |
·Wide supply voltage range (3V to 15V)
· High noise immunity (0.45 VCC typ)
· Low power consumption
· High capacitive load drive capability
· 3-STATE outputs
· Input protection
· TTL compatibility
· 20-pin dual-in-line package
· High speed 25 ns (typ.) @ 10V, 50 pF (MM74C244)
MM74C240
PDF/DataSheet Download
