MM74HC02 General Description
MM74HC02 Maximum Ratings
Supply Voltage (VCC) -0.5 to +7.0V
DC Input Voltage (VIN) -1.5 to VCC +1.5V
DC Output Voltage (VOUT) -0.5 to VCC +0.5V
Clamp Diode Current (IIK, IOK) ±20 mA
DC Output Current, per pin (IOUT) ±25 mA
DC VCC or GND Current, per pin
(ICC) ±50 mA
Storage Temperature Range (TSTG) -65°C to +150°C
Power Dissipation (PD)
(Note 3) 600 mW
S.O. Package only 500 mW
Lead Temperature (TL)
(Soldering 10 seconds) 260°C
MM74HC02 Features
Typical propagation delay: 8 ns
Wide power supply range: 26V
Low quiescent supply current: 20 A maximum (74HC Series)
Low input current: 1 A maximum
High output current: 4 mA minimum
