Purchase MMSZ2V4ET1, In-stock MMSZ2V4ET1 From SeekIC.
Part Number: MMSZ2V4ET1
Description: Three complete series of Zener diodes are offered in the convenient, surface mount plastic SOD-123 pac...
- Table of contents:
MMSZ2V4ET1
-
Suppliers
DataSheet
General Description
MMSZ2V4ET1 General Description
Three complete series of Zener diodes are offered in the convenient, surface mount plastic SOD-123 package. These devices provide a convenient alternative to the leadless 34-package style.
MMSZ2V4ET1 Maximum Ratings
|
Rating |
Symbol |
Max |
Unit |
| Peak Power Dissipation @ 20 s (Note 1) @ TL 25 |
Ppk |
225 |
Watts |
| Total Power Dissipation on FR-5 Board, (Note 2) @ TL = 75 Derated above 75 |
PD |
500 6.7 |
mW mW/ |
| Thermal Resistance - Junction-to-Ambient (Note 3) |
R JA |
340 |
/W |
| Thermal Resistance - Junction-to-Lead (Note 3) |
R JL |
150 |
/W |
| Junction and Storage Temperature Range |
TJ , Tstg |
-55 to +150 |
Maximum ratings are those values beyond which device damage can occur.
Maximum ratings applied to the device are individual stress limit values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied, damage may occur and reliability may be affected.
`Nonrepetitive current pulse per Figure 11
`FR-5 = 3.5 X 1.5 inches, using the On minimum recommended footprint as shown in Figure 12.
`Thermal Resistance measurement obtained via infrared Scan Method
MMSZ2V4ET1 Features
· 500 mW Rating on FR-4 or FR-5 Board
· Wide Zener Reverse Voltage Range - 2.4 V to 56 V
· Package Designed for Optimal Automated Board Assembly
· Small Package Size for High Density Applications
· ESD Rating of Class 3 (>16 kV) per Human Body Model
· Peak Power - 225 W (8 X 20 s)
