MFG:PANASONI.. Package Cooled:98+ D/C:QFP
MFG: PANASONI..
Package Cooled: 98+
D/C: QFP
Description: The MN657021F is a high-speed 8-bit, 3-channel CMOS digital-to-analog converter. (Two channels use ser...
The MN657021F is a high-speed 8-bit, 3-channel CMOS digital-to-analog converter. (Two channels use serial input.)
It uses both a matrix cell and weighted current technology to achieve both low power consumption and high speed.
It provides independent output amplitude adjustment for the Y (luminance) and C (chroma) synchronization signals. The Y (luminance signal) can be superimposed with an external SYNC signal.
| Parameter | Symbol | Rating | Unit |
| Power supply voltage for digital circuits | DVDD | 0.3 to +7.0 | V |
| Power supply voltage for analog circuits | AVDD | 0.3 to +7.0 | V |
| Input voltage | VI | 0.3 to DVDD +0.3 | V |
| Output voltage | VO | 0.3 to AVDD +0.3 | V |
| Operating ambient temperature | Topr | 20 to +70 | °C |
| Storage temperature | Tstg | 55 to +125 | °C |
MN657021F
PDF/DataSheet Download
