Purchase MP4015, In-stock MP4015 From SeekIC.
MFG:N/A Package Cooled:NA/ D/C:09+
- Table of contents:
MP4015
-
Suppliers
DataSheet
General Description
MP4015 Maximum Ratings
| Characteristics |
Symbol |
Rating |
Unit | |
| Collector-base voltage |
VCBO |
55 |
V | |
| Collector-emitter voltage |
VCEO |
60 ± 10 |
V | |
| Emitter-base voltage |
VEBO |
6 |
V | |
| Collector current | DC |
IC |
5 |
A |
| Pulse |
ICP |
8 | ||
| Continuous base current |
IB |
0.5 |
A | |
| Collector power dissipation (1 device operation) |
PC |
2.0 |
W | |
| Collector power dissipation (4 devices operation) |
PT |
4.0 |
W | |
| Junction temperature |
Tj |
150 |
| |
| Storage temperature range |
Tstg |
−55 to 150 |
| |
MP4015 Typical Application
`Small package by full molding (SIP 10 pin)
` High collector power dissipation (4 devices operation) : PT = 4 W (Ta = 25 )
`High collector current: IC (DC) = 5 A (max)
`High DC current gain: hFE = 1000 (min) (VCE = 4 V, IC = 3 A)
`Zener diode included between collector and base.
`Unclamped inductive load energy: ES/B = 100 mJ (min)
` High collector power dissipation (4 devices operation) : PT = 4 W (Ta = 25 )
`High collector current: IC (DC) = 5 A (max)
`High DC current gain: hFE = 1000 (min) (VCE = 4 V, IC = 3 A)
`Zener diode included between collector and base.
`Unclamped inductive load energy: ES/B = 100 mJ (min)
MP4015
PDF/DataSheet Download
- Datasheet: MP4015
- File Size: 145225 KB
- Manufacturer: TOSHIBA [Toshiba Semiconductor]
- Click here to Download
