MP7610

VCC to AGND . . . . . . . . . . . . . . . . . . . . . . . . . . . +16.5 V
VEE to AGND . . . . . . . . . . . . . . . . . . . . . . . . . . . --16.5 V
DVDD to DGND . . . . . . . . . . . . . . . . . . . . . . . . . . +6.5 V
VREF to DGND . . . . . . . . . . . . . . . . . . . . . . . . . . . +7.0 V
AGND to DGND . . . . . . . . . . . . . . . . . . . . . . . . . . . . +1 V
(Functionality guaranteed for ¦0.5 V only)
Digital Input & Output Voltage
to DGND . . . . . . . . . . . . . . . . . .. .. . --0.5 to DVDD +0.5V
Analog Inputs & Outputs . . ... . . ... . Indefinite Shorts to
VCC, VEE, DVDD, AGND, DGND (provided that power
dissipation of the package spec is not exceeded)
Operating Temperature Range
Extended Industrial . . . . . . . . . . . . . . --40°C to +85°C
Maximum Junction Temperature . ..... . --65°C to 150°C
Storage Temperature . . . . . . . . . . . . . . . .. . . . . . 150°C
Lead Temperature (Soldering, 10 sec) . . . . ...... +300°C
Package Power Dissipation Rating @ 75°C
SOIC, PLCC . . . . . . . . . . . . . . . . . . . . . . . . . . . 1150mW
Derates above 75°C . . . . . . . . . . . . . . . . . . . . 15mW/°C

NOTES:
1 Stresses above those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. This is a stress rating only and functional operation at or above this specification is not implied. Exposure to maximum rating conditions for extended periods may affect device reliability.
2 Any input pin which can see a value outside the absolute maximum ratings should be protected by Schottky diode clamps (HP5082-2835) from input pin to the supplies. All inputs have protection diodes which will protect the device from short transients outside the supplies of less than 100mA for less than 100ms.

TheMP7610 provides eight independent 14-bit resolution Digital-to-Analog Converters with voltage output amplifiers and a 3-wire standard serial digital address and data port.

The output amplifier MP7610 is capable of sinking and sourcing 5mA, and the output voltage settles to 12-bits in less than 30ms (typ.).

The MP7610 is equipped with a serial data (3-wire standard) m-processor logic interface to reduce pin count, package size, and board space.

Built using an advanced linear BiCMOS, these devices offer rugged solutions that are latch-up free, and take advantage of EXAR's patented thin-film resistor process which exhibits excellent long term stability and reliability.
