MQ200P

The MQ200P is one member of the TMQ200P family which is designed as the topstek current transducer that can be used in wide range of applications such as (1)UPS systems; (2)Process control devices; (3)AC and DC servo systems; (4)Motor speed controller; (5)Electrical vehicle controllers; (6)Inverter-controlled welding machines; (7)General and special purpose inverters; (8)Controller for traction equipment e.g. electric trains.

Features of the MQ200P are:(1)Highly reliable Hall Effect device; (2)Compact and light weight; (3)Fast response time; (4)Excellent linearity of the output voltage over a wide input range; (5)Excellent frequency response (> 50 kHz); (6)Low power consumption (16 mA nominal); (7)Capable of measuring both DC and AC, both pulsed and mixed; (8)High isolation voltage between the measuring circuit and the; (9)current-carrying conductor (AC2.5KV); (10)Extended operating temperature range; (11)Flame-Retardant plastic case and silicone encapsulate, using UL classified materials, ensures protection against environmental contaminants and vibration over a wide temperature and humidity range.

The absolute maximum ratings of the MQ200P can be summarized as:(1)Nominal Input Current: 200 A;(2)Linear Range: ±600 A;(3)Nominal Output Voltage: 4 V±1% at If=Ifn ( RL=10k);(4)Offset Voltage: Within ±15 mV @ If=0, Ta=25°C;(5)Output Resistance: <10 ;(6)Hysteresis Error: Within ±10 mV @ If=Ifn0;(7)Supply Voltage: ±15V ±5%;(8)Linearity: Within ±0.5% of Ifn;(9)Consumption Current: ±16 mA nominal;(10)Response Time (90%Vhn): 3 sec max. @ d If /dt = Ifn / sec. If you want to know more information about it, please download the datasheet in www.seekic.com or www.chinaicmart.com .
