MSP 3415D
-
Suppliers
DataSheet
General Description
MSP 3415D Maximum Ratings
|
Symbol |
Parameter |
Pin Name |
Min. |
Max. |
Unit |
|
TA |
Ambient Operating Temperature |
0 |
701) |
||
|
TS |
Storage Temperature |
-40 |
125 |
||
|
VSUP1 |
First Supply Voltage |
AHVSUP |
-0.3 |
9.0 |
V |
|
VSUP2 |
Second Supply Voltage |
DVSUP |
-0.3 |
6.0 |
V |
|
VSUP3 |
Third Supply Voltage |
AVSUP |
-0.3 |
6.0 |
V |
|
dVSUP23 |
Voltage between AVSUP and DVSUP |
AVSUP,DVSUP |
-0.5 |
0.5 |
V |
|
PTOT |
Package Power Dissipation PSDIP64 PSDIP52 PQFP80 PLQFP64 PMQFP44 |
AHVSUP, DVSUP, AVSUP |
1200 1300 1200 1000 9601) |
mW mW mW mW mW | |
|
VIdig |
Input Voltage, all Digital Inputs |
-0.3 |
VSUP2+ 0.3 |
V | |
|
IIdig |
Input Current, all Digital Pins |
-20 |
+20 |
mA2) | |
|
VIana |
Input Voltage, all Analog Inputs |
SCn_IN_s,MONO_IN3) |
-0.3 |
VSUP2+ 0.3 |
V |
|
IIana |
Input Current, all Analog Inputs |
SCn_IN_s,MONO_IN3) |
-5 |
+5 |
mA2) |
|
IOana |
Output Current, all SCART Outputs |
SC1_OUT_s3) |
4) 5) , |
4) 5) , |
|
|
IOana |
Output Current, all Analog Outputs except SCART Outputs |
DACM_s3) |
4) |
4) |
|
|
ICana |
Output Current, other pins connected to capacitors |
CAPL_M3), AGNDC |
4) |
4) |
1)For PMQFP44 package, max. ambient operating temperature is 65 °C.
2)positive value means current flowing into the circuit
3)"n" means "1" or "2", "s" means "L" or "R"
4)The Analog Outputs are short circuit proof with respect to First Supply Voltage and Ground.
5)Total chip power dissipation must not exceed absolute maximum rating.
Stresses beyond those listed in the "Absolute Maximum Ratings" may cause permanent damage to the device. This
is a stress rating only. Functional operation of the device at these or any other conditions beyond those indicated in the "Recommended Operating Conditions/Characteristics" of this specification is not implied. Exposure to absolute maxi-mum ratings conditions for extended periods may affect device reliability.
MSP 3415D Features
Specific MSP 3415D Features
· All NICAM standards
· Precise bit-error rate indication
· Automatic switching from NICAM to FM/AM or vice versa
· Improved NICAM synchronization algorithm
MSP01
PDF/DataSheet Download
- Datasheet: MSP01
- File Size: 33498 KB
- Manufacturer: VISAY [Vishay Siliconix]
- Click here to Download
