MT4S06

Features of the MT4S06  are:(1)Jlow noise figure:NF=1.6dB(VCE=3V,IC=3mA,f=2GHz);(2)high gain :gain=11.5 dB(VCE=3V,IC=7mA,f=2GHz).

The absolute maximum ratings of the MT4S06 can be summarized as:(1):the characteristic is collector-base voltage,the symbol is VCBO,the value is 10,the unit is V;(2):the characteristic is collector-emitter voltage,the symbol is VCEO,the value is 5,the unit is V;(3):the characteristic is emitter-base voltage,the symbol is VEBO,the value is 1.5,the unit is V;(4):the characteristic is base current,the symbol is IC,the value is 15,the unit is mA;(5):the characteristic is collector current,the symbol is IB,the value is 7,the unit is mA;(6):the characteristic is collector power dissipation,the symbol is PC,the value is 60,the unit is mW;(7):the characteristic is junction temperature,the symbol is Tj,the value is 125,the unit is ;(8):the characteristic is storage temperature range,the symbol is Tstg,the value is -55 to 125,the unit is .

The electrical characteristics of the MT4S06 can be summarized as:(1):the characteristic is collector cut off current,the symbol is ICBO,the Max is 0.1,the unit is A;(2):the characteristic is emitter cut off current,the symbol is IEBO,the Max is 1,the unit is A;(3):the characteristic is DC current gain,the symbol is hFE,the Min is 70,the Max is 140;(4):the characteristic is reverse transfer capacitance,the symbol is Cre,the Typ is 0.23,,the Max is 0.7,the unit is pF.
