Position: Home  > All Categories> Integrated Circuits (ICs) > MT89L86

MT89L86

Features: • 3.3 volt supply• 5V tolerant inputs and TTL compatible outputs.• 256 x 256 or 512 x 256 switching configurations• 8-bit or 4-bit channel switching capability• Guarantees frame integrity for wideband channels• Automatic identification of ST-BUS/GCI in...

product image

MT89L86 Picture
See larger image
SeekIC No. : 004430143 Detail

MT89L86: Features: • 3.3 volt supply• 5V tolerant inputs and TTL compatible outputs.• 256 x 256 or 512 x 256 switching configurations• 8-bit or 4-bit channel switching capability̶...

MT89L86 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MT89L86
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/8

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• 3.3 volt supply
• 5V tolerant inputs and TTL compatible outputs.
• 256 x 256 or 512 x 256 switching configurations
• 8-bit or 4-bit channel switching capability
• Guarantees frame integrity for wideband channels
• Automatic identification of ST-BUS/GCI interfaces
• Accepts serial streams with data rates of 2.048, 4.096 or 8.192 Mb/s
• Rate conversion from 2.048 Mb/s to 4.096 or 8.192 Mb/s and vice-versa
• Programmable frame offset on inputs
• Per-channel three-state control
• Per-channel message mode
• Control interface compatible to Intel/Motorola CPUs
• Low power consumption


Application

• Medium size mixed voice and data switching/ processing matrices
• Hyperchannel switching (e.g., ISDN H0)
• MVIP™ interface functions
• Serial bus control and monitoring
• Centralized voice processing systems
• Voice/Data multiplexer
• ADPCM 32 kbit/s channel switching


Pinout

Connection Diagram


Specifications

  Parameter Symbol Min Max Units
1 Supply Voltage   -0.3 5.0 V
2 Voltage on any I/O pin (except supply pins) VO VSS-0.3 VDD+0.3 V
3 Current at Digital Outputs IO   20 mA
4 Storage temperature TS -55 +125 °C
5 Package power dissipation PD   1 W
* Exceeding these values may cause permanent damage. Functional operation under these conditions is not implied.


Description

The 3.3V Multiple Rate Digital Switch (MT89L86) is pin compatible with MITEL's 5V MT8986 and retains all of its functionality. This 3.3v device is designed to provide simultaneous non-blocking connections for up to 256 64kb/s channels or blocking connections for up to 512 64kb/s channels. The serial inputs and outputs of MT89L86 may have 32 to 128 64kb/s channels per frame with data rates ranging from 2048 up to 8192 kb/s. MT89L86 also provides per-channel selection between variable and constant throughput delays allowing voice and grouped data channels to be switched without corrupting the data sequence integrity.
