MFG:N/A Package Cooled:. D/C:08+
MFG: N/A
Package Cooled: .
D/C: 08+
Description: The MT9080 is a flexible memory module suitable for use as a basic building block in the construction ...
The MT9080 is a flexible memory module suitable for use as a basic building block in the construction of large digital switching matrices. It can be configured as either a Data Memory or a Connection Memory. Interface to the device is via 16 bit wide data and address busses. The MT9080 can operate with variable clock rates up to 16.7 MHz.
| Parameter | Symbol | Min | Max | Units | |
| 1 | Supply Voltage VDD-VSS | VDD | - 0.3 | 7 | V |
| 2 | All Input Voltages | Vi | VSS-0.3 | VDD + 0.3 | V |
| 3 | All Output Voltages | Vo | VSS-0.3 | VDD + 0.3 | V |
| 4 | Storage Temperature Range | TS | -40 | 125 | |
| 5 | Current at Digital Outputs | IO | 150 | mA | |
| 6 | Continuous Power Dissipation | PD | 2 | W |
MT9080
PDF/DataSheet Download
