MFG:MIT Package Cooled:PLCC
MFG: MIT
Package Cooled: PLCC
Description: The MT90820 Large Digital Switch has a non-blocking switch capacity of 2,048 x 2,048 channels at a ser...
The MT90820 Large Digital Switch has a non-blocking switch capacity of 2,048 x 2,048 channels at a serial bit rate of 8.192 Mb/s, 1,024 x 1,024 channels at 4.096 Mb/s and 512 x 512 channels at 2.048 Mb/s. The device has many features that are programmable on per stream or per channel basis, including message mode, input offset delay and high impedance output control.
Per stream input delay control is particularly useful for managing large multi-chip switches that transport both voice channel and concatenated data channels.
In addition, input stream can be individually calibrated for input frame offset using a dedicated pin.
| Parameter | Symbol | Min | Max | Units | |
| 1 | Supply Voltage | VDD | 6.0 | V | |
| 2 | Voltage on any pin I/O (other than supply pins) | VI | VSS - 0.3 | VDD+0.3 | V |
| 3 | Continuous Current at digital outputs | IO | 20 | mA | |
| 4 | Package power dissipation (PLCC & PQFP) | PD | 2 | W | |
| 5 | Storage temperature | TS | - 65 | +125 |
MT90820AP
PDF/DataSheet Download
The MT90820AL1 Large Digital Switch has a non-blocking switch capacity of 2,048 x 2,048 channels at a serial bit rate of 8.192 Mb/s, 1,024 x 1,024 channels at 4.096 Mb/s and 512 x 512 channels at 2.048 Mb/s. The MT90820AL1 has many features that are programm...
The MT90820AL Large Digital Switch has a non-blocking switch capacity of 2,048 x 2,048 channels at a serial bit rate of 8.192 Mb/s, 1,024 x 1,024 channels at 4.096 Mb/s and 512 x 512 channels at 2.048 Mb/s. The MT90820AL has many features that are programmab...
The MT90820 Large Digital Switch has a non-blocking switch capacity of 2,048 x 2,048 channels at a serial bit rate of 8.192 Mb/s, 1,024 x 1,024 channels at 4.096 Mb/s and 512 x 512 channels at 2.048 Mb/s. The MT90820 has many features that are programmable o...
By integrating key functions needed in voice telecom application, the Integrated Digital Switch (IDX) of MT90812 provides a solution-on-a-chip for key telephone systems, PBX applications or CTI designs. Figure 2 shows a typical configuration.The MT90812 prov...
Mitel's MT90810 is a Flexible MVIP Interface Circuit (FMIC). The MVIP (Multi-Vendor Integration Protocol) compliant device provides a complete MVIP compliant interface between the MVIP Bus and a wide variety of processors, telephony interfaces and other circ...
The MT9080B is a flexible memory module suitable for use as a basic building block in the construction of customized digital switching matrices. MT9080B can be configured as either a Data Memory or a Connection Memory, and is designed to interface with Mitel...
