MFG:MITEL Package Cooled:PLCC
MFG: MITEL
Package Cooled: PLCC
Description: The MT9092 HPhone-II is a fully featured integrated digital telephone circuit which includes an HDLC d...
The MT9092 HPhone-II is a fully featured integrated digital telephone circuit which includes an HDLC data formatter. Voice band signals are converted to digital PCM and vice versa by a switched capacitor Filter/Codec. The Filter/Codec uses an ingenious differential architecture to achieve low noise operation over a wide dynamic range with a single 5V supply. A Digital Signal Processor provides handsfree speaker-phone operation. The DSP is also used to generate tones (DTMF, Ringer and Call Progress) and control audio gains. Internal registers are accessed through a serial microport conforming to INTEL MCS-51™ specifications. The device is fabricated in Mitel's low power ISO2-CMOS technology.
| Parameter | Symbol | Min | Max | Units | |
| 1 | Supply Voltage | VDD-VSS | -0.3 | 7 | V |
| 2 | Voltage on any I/O pin | VI/VO | VSS-0.3 | VDD+0.3 | V |
| 3 | Current on any I/O pin (transducers excluded) | II/IO | ±20 | mA | |
| 4 | Storage Temperature | TS | -65 | +150 | |
| 5 | Power Dissipation (package) Plastic | PD | 750 | mW | |
| 6 | Static Discharge | ESD | ±2.0 | KV | |
| 7 | Latch-up Current | ILU | ±100 | mA |
MT9092AP
PDF/DataSheet Download
The MT9092 HPhone-II is a fully featured integrated digital telephone circuit which includes an HDLC data formatter. Voice band signals are converted to digital PCM and vice versa by a switched capacitor Filter/Codec. The Filter/Codec MT9092 uses an ingeniou...
