MFG:MT Package Cooled:SMD D/C:05+
MFG: MT
Package Cooled: SMD
D/C: 05+
Description: The MT9160 5V Multi-featured Codec incorporates a built-in Filter/Codec, gain control and programmable...
The MT9160 5V Multi-featured Codec incorporates a built-in Filter/Codec, gain control and programmable sidetone path as well as on-chip anti-alias filters, reference voltage and bias source. The device supports both A-Law and m-Law requirements. Complete telephony interfaces are provided for connection to handset transducers. Internal register access is provided through a serial microport compatible with various industry standard micro-controllers. The device also supports controllerless operation utilizing the default register conditions. The MT9160 is fabricated in Mitel's ISO2-CMOS technology ensuring low power consumption and high reliability.
| Parameter | Symbol | Min | Max | Units | |
| 1 | Supply Voltage | VDD - VSS | - 0.3 | 7 | V |
| 2 | Voltage on any I/O pin | VI/VO | VSS - 0.3 | VDD + 0.3 | V |
| 3 | Current on any I/O pin (transducers excluded) | II/IO | ± 20 | mA | |
| 4 | Storage Temperature | TS | - 65 | + 150 | |
| 5 | Power Dissipation (package) | PD | 750 | mW |
• Programmable m-Law/A-Law Codec and Filters
• Programmable CCITT (G.711)/sign-magnitudecoding
• Programmable transmit, receive and side-tonegains
• Fully differential interface to handsettransducers - including 300 ohm receiver driver
• Flexible digital interface including ST-BUS/SSI
• Serial microport or default controllerless mode
• Single 5 volt supply
• Low power operation
• CCITT G.714 compliant
MT9160
