Part Number: MTD8N06E



MFG: ON

Package Cooled: 05+

D/C: TO-252

Description: This advanced TMOS EFET is designed to withstand high energy in the avalanche and commutation modes. The new energy eff...


Urgent Purchase

MTD8N06E General Description


This advanced TMOS EFET is designed to withstand high energy in the avalanche and commutation modes. The new energy efficient design also offers a draintosource diode with a fast recovery time. Designed for low voltage, high speed switching applications in power supplies, converters and PWM motor controls, these devices are particularly well suited for bridge circuits where diode speed and commutating safe operating areas are critical and offer additional safety margin against unexpected voltage transients.

MTD8N06E Maximum Ratings


Rating
Symbol
Value
Unit
DraintoSource Voltage
VDSS
60
Vdc
DraintoGate Voltage (RGS = 1.0 M)
VDGR
60
Vdc
GatetoSource Voltage - Continuous
GatetoSource Voltage - Nonrepetitive (tp 10 ms)
VGS
VGSM
±20
±30
Vdc
Vpk
Drain Current - Continuous
- Continuous @ 100°C
- Single Pulse (tp 10 s)
ID
ID
IDM
8.0
6.4
24
Adc

Apk
Total Power Dissipation @ 25°C
Derate above 25°C
Total Power Dissipation @ TA = 25°C, when mounted to minimum recommended pad size
PD
40
0.32
1.75
Watts
W/°C
Watts
Operating and Storage Temperature Range
TJ, Tstg
55 to 150
°C
Single Pulse DraintoSource Avalanche Energy - STARTING TJ = 25°C
(VDD = 25 Vdc, VGS = 10 Vdc, PEAK IL = 5 Apk, L = 10 mH, RG = 25)
EAS
96
mJ
Thermal Resistance - Junction to Case
- Junction to Ambient
- Junction to Ambient when mounted to minimum recommended pad size
RJC
RJA
RJA
3.13
100
71.4
°C/W

Maximum Lead Temperature for Soldering Purposes, 1/8"from Case for 10 seconds
TL
260
°C
Designer's Data for "Worst Case" Conditions - The Designer's Data Sheet permits the design of most circuits entirely from the information presented. SOA Limit
curves - representing boundaries on device characteristics - are given to facilitate "worst case" design.

EFET and Designer's are trademarks of Motorola, Inc. TMOS is a registered trademark of Motorola, Inc.
Thermal Clad is a trademark of the Bergquist Company.

MTD8N06E Features

• Avalanche Energy Specified
• SourcetoDrain Diode Recovery Time Comparable to a Discrete Fast Recovery Diode
• Diode is Characterized for Use in Bridge Circuits
• IDSS and VDS(on) Specified at Elevated Temperature
• Surface Mount Package Available in 16 mm, 13inch/2500 Unit Tape & Reel, Add T4 Suffix to Part Number

MTD8N06E datasheet

MTD8N06E
