MUR880E

Rectifiers 800V 8A UltraFast

product image

MUR880E Picture
See larger image
SeekIC No. : 00182211 Detail

MUR880E: Rectifiers 800V 8A UltraFast

MUR880E Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MUR880E
Mfg:
ON Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2026/1/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Ultra Fast Recovery Rectifiers Configuration : Single
Reverse Voltage : 800 V Forward Voltage Drop : 1.8 V
Recovery Time : 100 ns Forward Continuous Current : 8 A
Max Surge Current : 100 A Reverse Current IR : 25 uA
Mounting Style : Through Hole Package / Case : TO-220AC
Packaging : Tube

Description

Product : Ultra Fast Recovery Rectifiers
Configuration : Single
Forward Continuous Current : 8 A
Reverse Voltage : 800 V
Mounting Style : Through Hole
Packaging : Tube
Package / Case : TO-220AC
Max Surge Current : 100 A
Forward Voltage Drop : 1.8 V
Recovery Time : 100 ns
Reverse Current IR : 25 uA


Features:

• 20 mJ Avalanche Energy Guaranteed
• Excellent Protection Against Voltage Transients in Switching Inductive Load Circuits
• Ultrafast 75 Nanosecond Recovery Time
• 175°C Operating Junction Temperature
• Popular TO−220 Package
• Epoxy Meets UL 94 V−0 @ 0.125 in.
• Low Forward Voltage
• Low Leakage Current
• High Temperature Glass Passivated Junction
• Reverse Voltage to 1000 V
• Pb−Free Package is Available


Specifications

Rating
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage MUR880E
MUR8100E
VRRM
VRWM
VR
800
1000
V
Average Rectified Forward Current
(Rated VR, TC = 150°C)
Total Device
IF(AV)
8.0
A
Peak Repetitive Forward Current
(Rated VR, Square Wave,
20 kHz, TC = 150°C)
IFM
16
A
Non−Repetitive Peak Surge Current
(Surge Applied at Rated Load Conditions Halfwave, Single Phase, 60 Hz)
IFSM
100
A
Operating Junction and StorageTemperatureRange
TJ, Tstg
-65 to +175
°C



Parameters:

Technical/Catalog InformationMUR880E
VendorON Semiconductor
CategoryDiscrete Semiconductor Products
Diode Type Standard
Voltage - DC Reverse (Vr) (Max)800V
Current - Average Rectified (Io)8A
Voltage - Forward (Vf) (Max) @ If1.8V @ 8A
Reverse Recovery Time (trr)100ns
Current - Reverse Leakage @ Vr25A @ 800V
SpeedFast Recovery =< 500ns, > 200mA (Io)
Mounting TypeThrough Hole, Radial
Package / CaseTO-220-2 (Straight Leads)
PackagingTube
Capacitance @ Vr, F-
Drawing Number*
Lead Free StatusContains Lead
RoHS StatusRoHS Non-Compliant
Other Names MUR880E
MUR880E
MUR880EOS ND
MUR880EOSND
MUR880EOS
