Package Cooled:SOP D/C:07+
Package Cooled: SOP
D/C: 07+
Description: The MV8870 / MV8870-1 is a complete DTMF receiver integrating both the bandsplit filter and digital decoder function...
The MV8870 / MV8870-1 is a complete DTMF receiver integrating both the bandsplit filter and digital decoder functions, fabricated in GPS's double-poly ISO2-CMOS technology. The filter section uses switched capacitor techniques for high and low group filters; the decoder uses digital counting techniques to detect and decode all 16 DTMF tone pairs into a 4-bit code.
External component count is minimised by on-chip provision of a differential input amplifier, clock oscillator and latched 3-state bus interface.
The MV8870 and MV8870-1 are functionally identical, but differ in Electrical Characteristics.
| Parameter | Symbol | Value (MV8870) | Value (MV8870-1) | Units | ||
| Min | Max | Min | Max | |||
| Positive supply voltage (Pin 18) | VDD | +6.0 | +6.0 | V | ||
| Voltage on any pin (other than supplies) | VMAX | -0.3 | VDD + 0 3 | -0 3 | VDD + 0 3 | |
| Current at any pin (other than supplies) | IMAX | 10 | 10 | mA | ||
| Storage temperature | TSTG | -65 | +150 | -65 | +150 | |
| Package power dissipation | PP | 1000+ | 1000+ | mW | ||
MV8870-1
PDF/DataSheet Download
The MV8870 / MV8870-1 is a complete DTMF receiver integrating both the bandsplit filter and digital decoder functions, fabricated in GPS's double-poly ISO2-CMOS technology. The filter section uses switched capacitor techniques for high and low group filters;...
