Purchase MX23L8111, In-stock MX23L8111 From SeekIC.
- Table of contents:
MX23L8111
-
Suppliers
DataSheet
General Description
MX23L8111 Maximum Ratings
| Item | Symbol | Ratings |
| Voltage on any Pin Relative to VSS |
VCC |
-1.3V to VCC+2.0V (Note) |
| Ambient Operating Temperature |
Topr |
0°C to 70°C |
|
Storage Temperature |
Tstg |
-65°C to 125°C |
Note:
Minimum DC voltage on input or I/O pins is -0.5V.During voltage transitions, inputs may undershoot VSS to -1.3V for periods of up to 20ns. Maximum DC voltage on input or I/O pins is VCC+0.5V. During voltage transitions,input may overshoot VCC to VCC+2.0V for periods of up to 20ns.
MX23L8111 Features
• Bit organization
- 1M x 8 (byte mode)
- 512K x 16 (word mode)
• Fast access time
- Random access: 100ns
- Page access: 50ns (max.)
• Current
- Operating: 20mA
- Standby: 20uA
• Supply voltage
- 100ns @3.0V ~ 3.6V
- 120ns @2.7V ~ 3.6V
• Package
- 44 pin SOP (500mil)
- 42 pin PDIP (600mil)
- 48 pin TSOP (type 1)
- 44 pin TSOP (type 2)
- 1M x 8 (byte mode)
- 512K x 16 (word mode)
• Fast access time
- Random access: 100ns
- Page access: 50ns (max.)
• Current
- Operating: 20mA
- Standby: 20uA
• Supply voltage
- 100ns @3.0V ~ 3.6V
- 120ns @2.7V ~ 3.6V
• Package
- 44 pin SOP (500mil)
- 42 pin PDIP (600mil)
- 48 pin TSOP (type 1)
- 44 pin TSOP (type 2)
MX23L8111 Connection Diagram
MX23L8111
PDF/DataSheet Download
- Datasheet: MX23L8111
- File Size: 47861 KB
- Manufacturer:
- Click here to Download
