Product Details

Description



Features:

*  Low cost
*  Low leakage
*  Low forward voltage drop
*  High current capability
*  High surge current capability


Specifications

PARAMETER
SYMBOL
 P600A
6A05		 P600B
6A1		 P600D
6A2		 P600G
6A4		 P600J
6A6
P600K
6A8
 P600M
6A10		 UNITS
Maximum Recurrent Peak Reverse Voltage
VRRM
50
100
200
400
600
800
1000
Volts
Maximum RMS Voltage
VRMS
35
70
140
280
420
560
700
Volts
Maximum DC Blocking Voltage

 VDC

 50

 100

 200

 400

 600

 800

 1000


Volts
Maximum Average Forward Rectified Current at TA = 60
IO
6.0
Amps
Peak Forward Surge Current 8.3 ms single half sine-wave
Superimposed on rated load (JEDEC Method)
IFSM
400
Amps
Maximum Instantaneous Forward Voltage at 6.0A DC
VF
1.1
Volts
Maximum DC Reverse Current at
Rated DC Blocking Voltage		 @TA =25

IR
10
 uAmps
@TA =100
500
Maximum Full Load Reverse Current Average, Ful
Cycle .375*(9.5mm) lead length at TL = 75
50
 uAmps
Typical Junction Capacitance ( Note )

CJ
150

pF

Typical Thermal Resistance
RJC
10
/W
Operating and Storage Temperature Range
TJ,TSTG
-65 to +175
