P6010

Features of the P6010 are:(1)current transfer ratio CTR:Min.60 at IF=±1mA Vce=5V;(2)high isolation voltage between input and output(Viso:5000Vrms);(3)compact dual-in-line package;(4)AC input.

Applications of the P6010 are:(1)programmable controller applications for low input photocouplers and high Vceo photocouplers;(2)telephone sets,telephone exchangers;(3)system applances.Limit switches,sensors,thermostats,transdusers etc.;(4)signal transmission between circuit of different potentials and impedances.

The absolute maximum ratings of the P6010 can be summarized as:(1):the symbol is IF,the parameter is forward current,the rating is ±50,the unit is mA;(2):the symbol is IFM,the parameter is peak forward curent,the rating is ±1,the unit is A;(3):the symbol is PD,the parameter is power dissipation,the rating is 70,the unit is mW;(4):the symbol is VCEO,the parameter is collector-emitter voltage,the rating is 60,the unit is V;(5):the symbol is VECO,the parameter is emitter- collector voltage,the rating is 6,the unit is V;(6):the symbol is VCBO,the parameter is collector-base voltage,the rating is 60,the unit is V;(7):the symbol is VEBO,the parameter is emitter-base voltage,the rating is 6,the unit is V;(8):the symbol is IC,the parameter is collector current,the rating is 50,the unit is mA;(9):the symbol is Pc,the parameter is collector power dissipation,the rating is 150,the unit is mW;(10):the symbol is Ptot,the parameter is total power dissipation,the rating is 200,the unit is mW;(11):the symbol is Viso,the parameter is isolation voltage 1 minute,the rating is 5000,the unit is Vrms;(12):the symbol is Tstg,the parameter is storage temperature range,the rating is -55 to +125,the unit is ;(13):the symbol is Topr,the parameter is operating temperature range,the rating is -30 to +100,the unit is ;(14):the symbol is Tsol,the parameter is soldering temperature 10 seconds,the rating is 260,the unit is .
