PC100

The PC100 is designed as one kind of long creepage distance type photocoupler with four features:(1)long creepage distance type(creepage distance:8 mm or more);(2)internal insulation distance:2 mm or more;(3)high isolation voltage between input and output(Viso=5000Vrms);(4)dual-in-line package.and the first point allows pin-to-pin distance minus PWB land space to be 8mm or more.It can be used in switching power supplies,home applicances and OA equipment for export to europe,system appliances,measuring instruments.

The absolute maximum ratings of the PC100 can be summarized as:(1)forward current:50 mA;(2)peak forward current:1 A;(3)reverse voltage:6 V;(4)power dissipation:70 mW;(5)collector-emitter voltage:35 V;(6)emitter-collector voltage:6 V;(7)collector-base voltage:35 V;(8)emitter-base voltage:6 V;(9)collector current:50 mA;(10)collector power dissipation:150 mW;(11)total power dissipation:200 mW;(12)isolation voltage:5000 Vrms;(13)operating temperature:-30 to +100;(14)storage temperature:-55 to +125;(15)soldering temperature:260.If you want to know more information such as the electrical-optical characteristics,please download the datasheet in www.seekic.com and www.chinaicmart.com
